Building HVAC

Keep a heavyweight, well-insulated single-zone building at its comfort setpoint through occupied hours and a night setback, with hydronic heating, over a week of heating-season weather. The cost is in euros: discomfort outside a 0.5 K band, plus the gas bill. The building's thermal mass is hidden and responds over tens of hours, so recovery from setback has to start well before the setpoint steps up.

import target_gym as tg

env, params = tg.make("hvac")

Action space	Box((1,)), all actions in [-1, 1]
Observation space	Box((7,))
Tracked variable(s)	zone air temperature (deg C)
Episode length	720 steps of 900 s (7.5 days)
Cite as	hvac-v2
Physics	contract

Action space

Actions are normalised to [-1, 1] and mapped onto the plant's real actuator range inside the environment.

#	meaning	min	max
0	commanded heating power	-1	1

Observation space

7 values in the plant's own units. The space declares no bounds (it spans the float32 range), so scale them before training. The reward scores obs[0] against obs[6].

#	meaning
0	zone air temperature (°C)
1	outdoor temperature (°C)
2	heat output, percent of maximum
3	solar irradiance, fraction of its peak
4	sine of the hour of day
5	cosine of the hour of day
6	target zone temperature (°C)

Rewards

See the environment's compute_reward.

Every environment in this suite scores on one contract. The reward is minus the sum of three non-negative costs, -(tracking_cost + running_cost + failure_cost). The running cost charges consumption and the failure cost charges trips out of the operating envelope. The reward is never positive, and its scale differs by orders of magnitude between plants. Some plants are priced in dollars or euros and the rest are dimensionless; the per-plant summary says which. See Reward shaping for how each cost is built.

Starting state

reset samples the initial condition and the target; state has 10 fields.

Episode end

Termination. None. terminated is always false: the plant keeps its state through a trip instead of restarting, and every step spent outside the envelope is charged the trip cost and sets info["tripped"] and info["trip_cost"] until the controller brings it back. See Reward shaping.

Truncation. After 720 steps.

Baselines

Recorded over 10 seeds of the 720-step episode (see Baseline results). The reward is a cost, so a return closer to zero is better.

controller	mean return	cost per step
PID	-16.28	0.02261
MPC	-8.106	0.01126

The MPC beats the PID on 10 of 10 seeds and does not trip the plant on any of them.

Arguments

The scored configuration, which tg.make returns. A keyword argument changes one field, as in tg.make("hvac", max_steps_in_episode=...).

parameter	value	unit
delta_t	900	s
max_steps_in_episode	720	steps
A_floor	150	m^2
lambda_at	4.5	-
f_class	2.5	-
cm_per_area	165000	J/(K m^2)
h_is	3.45	W/(m^2 K)
h_ms	9.1	W/(m^2 K)
A_wall	120	m^2
U_wall	0.28	W/(m^2 K)
A_roof	150	m^2
U_roof	0.18	W/(m^2 K)
A_window	25	m^2
U_window	1.3	W/(m^2 K)
g_window	0.55	-
air_changes_per_hour	0.5	1/h
room_height	2.6	m
Q_heat_max	7200	W
emitter_tau	900	s
T_out_mean	5	degC
T_out_amplitude	5	K
T_out_noise_std	3	K
solar_peak	350	W/m^2
gain_occupied	8	W/m^2
gain_unoccupied	2	W/m^2
occupied_start_h	7	h
occupied_end_h	22	h
setpoint_occupied	21	degC
setpoint_setback	17	degC
T_air_min	5	degC
precision_floor	0.1	K
T_air_max	35	degC
comfort_band	1	K
energy_weight	0	-
reward_version	2	-
comfort_tolerance	0.5	K
comfort_price	0.03	EUR/(K^2 h)
gas_price	0.1	EUR/kWh
tracking_exponent	2	-
failure_cost	4.335	reward
restart_steps	4	steps
rho_floor_tracking	0.001	reward
rho_floor	0.001	reward
