Reactor

Follow a drifting power demand on a 3 GW pressurised-water reactor with the control rods. Xenon poisoning gives the core a memory of hours, so a power change constrains what is reachable long after it is made; rod authority is tight and insertion is faster than withdrawal; and only power, coolant temperature and rod position are measured. Costs are in dollars.

import target_gym as tg

env, params = tg.make("reactor")

Action space	Box((1,)), all actions in [-1, 1]
Observation space	Box((4,))
Tracked variable(s)	neutron power (normalised)
Episode length	864 steps of 10 s (2.4 h)
Cite as	reactor-v3
Physics	contract

Action space

Actions are normalised to [-1, 1] and mapped onto the plant's real actuator range inside the environment.

#	meaning	min	max
0	rho_ext_norm	-1	1

Observation space

4 values in the plant's own units. The space declares no bounds (it spans the float32 range), so scale them before training. The reward scores obs[0] against obs[3].

#	meaning
0	n, neutron power relative to nominal (1 is full power)
1	coolant temperature (K)
2	rod position, normalised to [-1, 1]
3	target n

Rewards

See the environment's compute_reward.

Every environment in this suite scores on one contract. The reward is minus the sum of three non-negative costs, -(tracking_cost + running_cost + failure_cost). The running cost charges consumption and the failure cost charges trips out of the operating envelope. The reward is never positive, and its scale differs by orders of magnitude between plants. Some plants are priced in dollars or euros and the rest are dimensionless; the per-plant summary says which. See Reward shaping for how each cost is built.

Starting state

reset samples the initial condition and the target; state has 12 fields.

Episode end

Termination. None by default. Leaving the operating envelope trips the plant: the step that leaves it is charged the trip cost and sets info["tripped"] and info["trip_cost"], and the plant restarts as reset_env would while the episode clock keeps running. Episodic use is optional: with continuing = False the plant is lost and terminated is raised on that step instead. See Reward shaping.

Truncation. After 864 steps.

Baselines

Recorded over 10 seeds of the 864-step episode (see Baseline results). The reward is a cost, so a return closer to zero is better.

controller	mean return	cost per step
PID	-5736	6.639
MPC	-1209	1.4

The MPC beats the PID on 10 of 10 seeds and does not trip the plant on any of them.

Arguments

The scored configuration, which tg.make returns. A keyword argument changes one field, as in tg.make("reactor", max_steps_in_episode=...).

parameter	value	unit
delta_t	1	s
max_steps_in_episode	864	steps
Lambda_gen	0.0001	s
alpha_fuel	-3e-05	1/K
alpha_coolant	-5e-05	1/K
T_fuel_ref	900	K
T_coolant_ref	580	K
rho_ext_min	-0.01	-
rho_ext_max	0.005	-
rod_speed_insert	0.0004	1/s
rod_speed_withdraw	0.0002	1/s
P_thermal_ref	3e+09	W
C_fuel	3.3e+07	J/K
C_coolant	7e+07	J/K
UA	6.6e+06	W/K
m_dot_cp	9e+07	W/K
T_inlet	555	K
sigma_phi0	7.95e-05	1/s
gamma_ratio	0.049	-
rho_Xe_full	0.025	-
n_min	0.01	-
precision_floor	0.0001	-
n_max	1.5	-
T_fuel_max	1473	K
T_fuel_min	500	K
T_coolant_max	620	K
T_coolant_min	500	K
rod_motion_weight	0.02	-
reward_band	0.03	-
demand_theta	0.00015	1/s
demand_sigma	0.0025	1/s^0.5
P_electric_GW	1	GW
spot_price_per_MWh	80	$/MWh
imbalance_factor	3	-
initial_T_fuel	900	K
initial_T_coolant	580	K
reward_version	2	-
e_floor	0.00451	-
e_tol	0	-
tracking_exponent	1	-
imbalance_multiple	1.25	-
rod_wear_weight	1	-
failure_cost	666.667	reward
restart_steps	17280	steps
rho_floor_tracking	1.25278	reward
rho_floor	1.25278	reward
